Model: FDF-25V
LAB Category
Deep Freezer -25 °C Vertical
Deep Freezer -25°C is a high-precision cold storage unit crafted for the secure preservation of sensitive biologicals, including plasma, vaccines, and lab reagents. Its robust vertical design, user-centric interface, and intelligent temperature management system make it a trusted choice for laboratories, hospitals, and biotech facilities. Built to excel in demanding conditions, it seamlessly combines technical performance, energy efficiency, and global safety compliance.
Precision Cooling Control (–10°C to –25°C): Stable, accurate temperature range ideal for biological storage.
Ergonomic & Durable Design: Vertical structure with stainless steel interior and powder-coated body.
Eco friendly Advanced Insulation: CFC-free high-density polyurethane insulation for thermal consistency.
Integrated Monitoring System: Digital display with alarms, event logs, and system alerts.
WHO & IEC Compliant: Conforms to international standards for electrical safety and cold chain.
Energy efficient Compressor System: Optimized for 24/7 operation with reduced power consumption.
Technical Specifications
| Specifications | Values |
|---|---|
| Model Number | FDF-25V |
| Make | Froven Innovations |
| Type of Cabinet | Vertical/Upright |
| Color | White |
| Outer Material | Corrosion resistance CRCA/GI powder steel (18swg) |
| Inner Material | Stainless Steel 304 |
| PUFF Insulation (Cabinet / Door) | 127 mm / 115 mm |
| Ground Clearance | 100 mm (Castor wheels, 2 Lockable) |
| Door Details | Solid door with Lock-Key, handle and 04 Nos Inner Door |
| Inner Shelves | 04 Nos |
| Compressor Type | Hermetically sealed |
| Refrigerants | R452A |
| Condensing | Skin condensing / forced air circulation |
| Pull down time | 04 Hours |
| Temperature uniformity | ±3˚C or Less |
| Environmental Condition | Maximum +45°C with Humidity 5% to 95% RH |
| Control System | Programmable microprocessor (Eye level panel) |
| Temperature Monitoring System | IOT Supported (Optional) | 7 days Chart Recorder (Optional) |
| Display | 7” Touch Screen Digital Display |
| Alarms | Audible and visual (Temp, Power, System, Clogged Filter, Door, Battery) |
| Battery Backup | 74 Hrs for Display, Alarms, and recording system |
| Access port | LN2/CO2 Backup provision |
| Power Consumption (Stable / Cool Down) | 2.040 kWh/24Hrs / 2.30kWh/24Hrs |
| Power supply | 100 to 290 VAC, 50 Hz +10% |
* Specifications, features, and design are subject to change without prior notice for product improvement.
